2D Reinforcement-Enabled Strip Footing Families for Revit

Enhance your drafting skills with precision and flexibility using these 2D reinforcement-enabled families for Revit. Whether you're detailing section views, incorporating fine-level details, or showing concrete sections within legends, these families offer comprehensive solutions for your construction needs.

https://youtu.be/xE3qW8uauJY

Included in this Package:

• Structural Framing Family: Impeccably designed strip footing family with editable reinforcement. Effortlessly modify bar numbers, sizes, and incorporate trench mesh. Choose the utilization of ligatures for added flexibility. (1 .rfa file)
• Structural Foundation Family: Purpose-built strip footing family with editable reinforcement, empowering you to customize bar numbers, sizes, and integrate trench mesh. The flexibility extends to opting for ligature use. (1 .rfa file)

What You'll Get:

• Seamless access to permanent updates: Stay ahead with every iteration as new versions are delivered promptly via your provided email address.

Important Note: Ensure compatibility by selecting the correct version corresponding to your Revit software before downloading.

Elevate your structural detailing and design efficiency. These families are crafted to augment your workflow, providing adaptability and precision in every project.
